Description:

This Ecomony Multi Function Garment Printer is designed for sampling and proofing , or short run of Apparel printing. This Apparel printer is mainly for Screen Printing Factory, Apparel Company, Fashion Companies and Designers etc.

Features:

• Advanced Re-circulation system of White Ink, least maintenance.
• Grand Pallet design, longer size print allowed.
• Laser sensor design keep printhead safer.
• Quality silent ball screw, Y transmission shaft is more durable and stable.
• Several windows designed for more convenient routine maintenance.

Specifications:

Main Engine: Epson 3890 ( 9 colors)

Rip software: HFRIP 2.0

Printing size: Max. 420mm*900mm

Printhead: Epson DX5 Printhead, 8*180 nozzle, VSDT

Colors: CMYK+ 4* white channels ( dark garment support)

Print Directions: Intelligent bi/single direction printing.

Speed: 180 seconds / piece (dark garments and women size)

Thickness of Printing: 0-125mm

Resolution: 2880*1440dpi

Ink: Dupont Artistri® P5000⁺ textile pigment ink.

Media: Cotton, Polyester, Cotton/polyester Blends, Lycra, Viscose, Silk, Linen, Wool and more.

Other consumables: Pretreatment solution for dark & light garments, Cleaning ink and head cleaning kit.

Height adjustment: Automatic/ manual operation

Head protection: Laser sensor automatic protection system.

Power: 110-220V, 50-60HZ, 95W

Interface: USB2.0/1.1, 1GB Ethernet,

Computer System: Windows XP/ Win7, Mac, Linus

Working Environment:  Temperature: 15-35℃, Humidity: 20-80RH

Size and Weight:    Printer: 1220X850X880MM, 128kg

Package: 1300X900X920MM,225kg
